Description
1: The machine operates with long stability to ensure high reliability and durability.
2: Advanced operating system, easy to operate, producing well without no complicated training.
3: Servo motors controlled spring spacing is precise and easy to adjust the mattress width.
4: High level of protection, more humanized,ensure production efficiency and stable production quality.
| Spring Type | Bonnell |
| Performance | Max.:100pcs/min;48000pcs/8hours |
| Spring Wire Diameter | 1.9mm-2.4mm(Choose one size ) |
| Spiral Wire Diameter | 1.3mm-1.5mm(Choose one size ) |
| Range of spring diameter’s mold | □66mm-68mm 口69mm-71mm □72mm-74mm□76mm-78mm □79mm-82mm □83mm-87mm □88mm-92mm(need to choose ) |
| Center Coil Outside Diameter | 32-55mm(Choose one size ) |
| Spring Height | 80-190mm 4 turns 80-120mm 5 turns 120-150mm (Choose one size ) 6 turns 140-190mm Standard:5turns |
| Working Width | 2000mm |
| Working Temperature | +5-+45℃ |
| Wire Basket Capacity | ≦1000 |
| Area of use | LxW 4600*5200mm |
| Weight | 3900KG |
| Power Requirements | 3P+N AC380V, 50-60Hz, instantaneous maximum 50A, cable 5*10mm² 3P+N AC380V, 50-60HZ，instantaneous maximum 50A,Cable5*10mm² |
| Air consumption | 0.6-0.7MPa |
| Gas source demand | 0.25m3/min |
| Power Consumption | 33 KW |
